General Specifications
61-000163-02 QX Cordset, Host, Ethernet, M12 8-pin Plug (Screw-On) to RJ45, 3M
61-000160-01 QX Cordset, Host, Ethernet, M12 8-pin Plug (Ultra-Lock) to RJ45, 1M
61-000160-02 QX Cordset, Host, Ethernet, M12 8-pin Plug (Screw-On) to RJ45, 1M
61-000161-01 QX Cordset, M12 12-pin Plug (Ultra-Lock) to MS-Connect 5100, 3M
61-000161-02 QX Cordset, M12 12-pin Plug (Screw-On) to MS-Connect 5100,3M
61-000172-01 QX Cordset, M12 12-pin Plug (Ultra-Lock) to M12 12-pin Socket (Ultra-Lock) to DB25 Plug
61-000158-03 QX Cordset, M12 12-pin Plug and M12 12-pin Socket to MS-Connect 210 (RS-232), 2m
61-000158-04 QX Cordset, M12 12-pin Plug and M12 12-pin Socket to MS-Connect 210 (RS-422), 2m
61-000166-01 QX Cordset, M12 12-pin Plug (Ultra-Lock) to Flying Leads, 3M
61-000166-02 QX Cordset, M12 12-pin Plug (Screw-On) to Flying Leads, 3M
61-000167-01 QX Cordset, M12 12-pin Socket (Ultra-Lock) to Flying Leads, 3M
61-000167-02 QX Cordset, M12 12-pin Socket (Screw-On) to Flying Leads, 3M
FIS-0210-0001G MS-Connect 210, Connectivity Box with Display
FIS-0210-0002G MS-Connect 210, Connectivity Box
FIS-0210-0003G MS-Connect 210, Connectivity Box with Display and Ethernet
FIS-0210-0004G MS-Connect 210, Connectivity Box with Ethernet
98-000013-04 Relay Module, 120VAC, 3 Amp Output,Series 70,Type SM,for MS-Connect 210 + MS-890
98-000013-05 Relay Module, 240VAC, 3 Amp Outpu t,Series 70,Type SM for MS-Connect 210 + MS-890
98-000013-06 Relay Module, 24VDC, 3 Amp Output, Series 70, Type SM for MS-Connect 210
61-000207-01 QX Cordset, Smart Series Light to QX-1, ON/OFF
61-000218-01 QX Cordset, Smart Series Light to QX-1, Strobe, NPN
61-000166-01 QX Cordset, M12 12-pin Plug (Ultra-Lock) to Flying Leads, 3M
61-000167-01 QX Cordset, M12 12-pin Socket (Ultra-Lock) to Flying Leads, 3M
20-610024-01 Trigger Conn, 4-pin Plug (Screw Terminal and Field-Wireable for Custom Wiring IB-131)
98-000037-01 Kit, Mounting Arm Extension, All Readers, 6 inch
98-000054-01 Kit, Mounting Stand Base Plate
98-000016-01 Kit, Mounting Arm/Adapter, MS-820/QX-830/QX-870, 6 inch
99-000056-01 Accessory, Bracket, Smart Series DOAL 50 to QX Hawk
99-000058-01 Accessory, Bracket, Smart Series DOAL 75 to QX Hawk
99-000060-01 Accessory, Bracket, Smart Series DOAL 100 to QX Hawk
99-000061-01 Accessory, Bracket, Smart Series DOAL to C-Mount QX Hawk
99-000050-01 Accessory, Bracket, Smart Series R-100 to QX Hawk
99-000052-01 Accessory, Bracket, Smart Series R-60/70 to QX Hawk
99-000049-01 Accessory, Bracket, Smart Series R-100 to C-Mount QX Hawk
99-000051-01 Accessory, Bracket, Smart Series R-60/70 to C-mount QX Hawk
98-000148-01 Kit, L-Bracket, QX Series
Object Detectors
99-000020-01 QX Photo Sensor, M12 4-pin Plug, NPN, Dark Off, 2m
99-000020-02 QX Photo Sensor, M12 4-pin Plug, NPN, Dark On, 2m
Documentation
37-000010-01 Microscan Tools Drive: Software, Documentation, Links to Microscan website
A-10
QX Hawk Industrial Imager User Manual
