Using EtherNet/IP
NET and MOD LED Indicators
MOD (Module)
Indicator State Summary
Steady OFF No power
Device
Steady GREEN
operational
Steady RED Major fault
Flashing GREEN /
Self-test
RED
NET (Network)
Indicator State Summary
No power, no
IP address
Steady OFF
Flashing GREEN No connections
Steady GREEN Connected
Connection
timeout
Flashing RED
Steady RED Duplicate IP
Flashing GREEN /
Self-test
RED
A-106
Requirement
If no power is supplied to the device, the
module status indicator will be steady
OFF.
If the device is operating correctly, the
module status indicator will be steady
GREEN.
If the device has detected a non-recoverable
minor fault, the module status indicator
will be steady RED.
While the device is performing its power-up
testing, the module status indicator will
be flashing GREEN / RED.
Requirement
If the device does not have an IP
address (or is powered off), the network
status indicator will be steady OFF.
If the device has no established connections,
but has obtained an IP address, the
network status indicator will be flashing
GREEN.
If the device has at least one established
connection (even to the Message
Router), the network status indicator will
be steady GREEN.
If one or more of the connections in
which the device is the target has timed
out, the network status indicator will be
flashing RED.
If the device has detected that its IP
address is already in use, the network
status indicator will be steady RED.
While the device is performing its
power-up testing, the module status
indicator will be flashing GREEN
QX Hawk Industrial Imager User Manual
Microscan
Implementation
Per requirement
Per requirement
Safe Mode: Basic
comm. only. Scanning
system non-functional.
Per requirement.
Microscan
Implementation
Per requirement.
Before device has
acquired an IP
address via DHCP.
Per requirement.
After device has
acquired an IP
address (static or
DHCP).
Per requirement.
Per requirement.
Not implemented.
Per requirement.
/ RED.
