Check Character Output Status (Interleaved 2 of 5)
Serial Cmd:
<K472,status,check character
length #1,symbol length #2,guard bar status,range mode status>
Default:
0 = Disabled
Options:
0 = Disabled
Symbol Length #1 (Interleaved 2 of 5)
Serial Cmd:
<K472,status,check character status,check character
#1,symbol length #2,guard bar status,range mode status>
Default:
16
Options:
0 to 128
Symbol Length #2 (Interleaved 2 of 5)
Serial Cmd:
<K472,status,check character status,check character output,symbol length
#1,symbol length
Default:
6
Options:
0 to 128
Guard Bar Status (Interleaved 2 of 5)
Serial Cmd:
<K472,status,check character status,check character output,symbol length
#1,symbol length
Default:
0 = Disabled
Options:
0 = Disabled
Range Mode Status (Interleaved 2 of 5)
Serial Cmd:
<K472,status,check character status,check character output,symbol length
#1,symbol length #2,guard bar
Default:
1 = Enabled
Options:
0 = Disabled
UPC/EAN
UPC Status (UPC/EAN)
Serial Cmd:
<K473,UPC
separator character,supplemental type,format UPC-E as UPC-A>
Default:
3 = Both Standard and Edge-to-Edge
Options:
0 = Disabled
1 = Standard
2 = Edge-to-Edge
3 = Both Standard and Edge-to-Edge
QX Hawk Industrial Imager User Manual
status,check character output
1 = Enabled
#2,guard bar status,range mode status>
#2,guard bar
status,range mode status>
1 = Enabled
status,range mode
1 = Enabled
status,EAN status,supplementals status,separator status,
Appendices
status,symbol
output,symbol length
status>
A-49
