Microscan QX Hawk User Manual page 325

CCD Modular Zoom Optics: Inches (mm)
Narrow Bar Width
1D 2D
0.002 (0.05) 0.0033 (0.08)
12° 0.005 (0.13) 0.0075 (0.19)
0.010 (0.25) 0.0150 (0.38)
0.020 (0.51) 0.0300 (0.76)
Narrow Bar Width
1D 2D
0.002 (0.05) 0.0033 (0.08)
15° 0.005 (0.13) 0.0075 (0.19)
0.010 (0.25) 0.0150 (0.38)
0.020 (0.51) 0.0300 (0.76)
Narrow Bar Width
1D 2D
0.002 (0.05) 0.0033 (0.08)
30° 0.005 (0.13) 0.0075 (0.19)
0.010 (0.25) 0.0150 (0.38)
0.020 (0.51) 0.0300 (0.76)
Narrow Bar Width
1D 2D
0.005 (0.13) 0.0075 (0.19)
45°
0.010 (0.25) 0.0150 (0.38)
0.020 (0.51) 0.0300 (0.76)
QX Hawk Industrial Imager User Manual
Read Range
(using autofocus)
Inside Edge
3.5 to 7 (87 to 178) 0.9 (23)
3.4 to 12 (86 to 304) 0.9 (23)
3.3 to 13 (83 to 330) 0.9 (23)
4 to 14 (101 to 355) 1.03 (26)
Read Range
(using autofocus)
Inside Edge
2 to 5 (51 to 127) 0.78 (20)
1.9 to 8.3 (48 to 210) 0.75 (19)
1.9 to 9.5 (47 to 241) 0.75 (19)
3 to 10.3 (76 to 261) 1.03 (26)
Read Range
(using autofocus)
Inside Edge
1 to 3 (25 to 76) 0.83 (21)
1 to 6.5 (25 to 165) 0.83 (21)
1 to 16 (25 to 406) 0.83 (21)
2 to 32 (51 to 813) 1.3 (33)
Read Range
(using autofocus)
Inside Edge
1 to 5 (25 to 127) 1.3 (33)
1 to 9.5 (25 to 241) 1.3 (33)
1 to 23.5 (25 to 597) 1.3 (33)
Field of View Depth of Field
Outside Edge Inside Edge
1.62 (41) 0.1 (3)
2.62 (66) 0.2 (5)
2.77 (70) 0.4 (10)
2.96 (75) 0.6 (15)
Field of View Depth of Field
Outside Edge Inside Edge
1.53 (39) 0.2 (5)
2.35 (60) 0.3 (8)
2.65 (67) 0.5 (13)
2.84 (72) 0.6 (15)
Field of View Depth of Field
Outside Edge Inside Edge
1.8 (46) 0.4 (10)
3.5 (89) 0.8 (20)
8.3 (211) 2 (51)
16.4 (417) 3 (76)
Field of View Depth of Field
Outside Edge Inside Edge
4.1 (104) 1.5 (38)
7.5 (191) 2 (51)
18.3 (465) 3.8 (97)
Appendices
Outside Edge
0.3 (8)
1 (25)
2.5 (64)
5 (127)
Outside Edge
0.4 (10)
1 (25)
3 (76)
4.5 (114)
Outside Edge
0.8 (20)
1.8 (46)
8.5 (216)
21.5 (546)
Outside Edge
2 (51)
6 (152)
19 (483)
A-7
