IP Address (Ethernet)
Serial Cmd: <K126,status,IP
Default: 192.168.0.100
Options: 0.0.0.0 – 255.255.255.255
Subnet (Ethernet)
Serial Cmd: <K126,status,IP address,subnet,gateway,IP address mode>
Default: 255.255.0.0
Options: 0.0.0.0 – 255.255.255.255
Gateway (Ethernet)
Serial Cmd: <K126,status,IP address,subnet,gateway,IP address mode>
Default: 0.0.0.0
Options: 0.0.0.0 – 255.255.255.255
IP Address Mode (Ethernet)
Serial Cmd: <K126,status,IP
Default: 0 = Static
Options: 0 = Static
Ethernet TCP Ports
TCP Port 1 (Ethernet TCP Ports)
Serial Cmd: <K127,TCP Port
Default: 2001
Options: 1024 – 65535
TCP Port 2 (Ethernet TCP Ports)
Serial Cmd: <K127,TCP Port
Default: 2003
Options: 1024 – 65535
RS-232 A Data Type
Symbol Data Output (RS-232 A Data Type)
Serial Cmd: <K130,symbol data
source processing mode>
Default: 1 = Enabled
Options: 0 = Disabled
QX Hawk Industrial Imager User Manual
address,subnet,gateway,IP address mode>
address,subnet,gateway,IP address
1 = DHCP
1,TCP Port 2>
1,TCP Port 2>
output,extended data,diagnostic output,external
1 = Enabled
Appendices
mode>
A-33
