Chapter 6: PLC Communications

Cables from AutomationDirect

6
6–14
Cable Description
AutomationDirect Productivity Series,
CLICK, Direct LOGIC PLC RJ-12 port,
DL05, DL06, DL105, DL205, D3-350,
D4-450 & H2-WinPLC (RS-232C)
Direct LOGIC (VGA Style) 15-pin port,
DL06, D2-250 (250-1), D2-260
(RS-232C).
Direct LOGIC PLC RJ-11 port, D3-340
(RS-232C).
Direct LOGIC DL405 PLC 15-pin D-sub
port, DL405 (RS-232C).
Direct LOGIC PLC 25-pin D-sub port,
DL405, D3-350, DL305 DCU and all DCM's
(RS-232C).
Allen-Bradley MicroLogix 1000, 1100,
1200 & 1500 (RS-232C)
Allen-Bradley SLC 5-03/04/05,
ControlLogix, CompactLogix, FlexLogix
DF1 port (RS-232C)
Allen-Bradley PLC-5 DF1 port
(RS-232C)
Allen-Bradley MicroLogix, SLC 5-01/02/03,
PLC5 DH485 port (RS-232C)
GE 90/30, 90/70, Micro 90, Versamax
Micro (Port2) 15-pin D-sub port
(RS-422A)
MITSUBISHI FX Series 25-pin port
(RS-422A)
MITSUBISHI FX Series 8-pin mini-DIN
(RS-422A)
OMRON Host Link (C200 Adapter, C500)
(RS-232C)
®
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
Cable Part No.
EA-2CBL
EA-2CBL-1
EA-3CBL
EA-4CBL-1
EA-4CBL-2
EA-MLOGIX-CBL
EA-SLC-232-CBL
EA-PLC5-232-CBL
EA-DH485-CBL
EA-90-30-CBL
EA-MITSU-CBL
EA-MITSU-CBL-1
EA-OMRON-CBL
