Chapter 3: Accessories
Accessories
Part Number
3
EA-MG-PGMSW
USB-CBL-AB6
Part Number
EA-4-COV2
Part Number
EA-MG6-BZ2
EA-MG6-BZ2P
EA-6-COV2
3–2
Micro-Graphic Programming Software & Programming Cable
Micro-Graphic Panel Accessory for 4-inch Panel
Micro-Graphic Panel Accessories for 6-inch Panels
®
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
Description
C-more Micro-Graphic panel Windows-based configuration software.
Requires Windows 2000 with Service Pack 4, XP Home or Professional
with Service Pack 2, Windows Vista or Windows 7. Requires USB port
connection from PC to touch panel. Includes CD-ROM. Programming
cable sold separately. Downloadable version available from the Web
site at no charge. Software Help Files included in download.
Standard USB 2.0 cable with Standard-A plug to Standard-B plug,
suitable for all USB devices. 6 ft. (1.8 m) cable shown as example.
Maximum cable length is 15 ft (4.5 m).
Description
Optional clear screen overlay used to protect C-more 4" Micro-Graphic
displays from minor scratches and wear. Package contains 3 clear
screen overlays.
Description
For Landscape (Horizontal) Mounted Panels. 20-button keypad bezel
with numeric keypad for C-more 6" Micro-Graphic panels, 4 arrow
adjust keys, and ESCAPE, MENU, CLEAR and ENTER buttons. Helps to
reduce screen wear in heavy-duty applications where operators can
use the keypad to enter numeric data. Designed for easy drop-in of the
Micro-Graphic panels.
For Portait (Vertical) Mounted Panels. 21-button keypad bezel with
numeric keypad for C-more 6" Micro-Graphic panels, 4 arrow adjust
keys, and ESCAPE, MENU, CLEAR and (2) ENTER buttons. Helps to
reduce screen wear in heavy-duty applications where operators can
use the keypad to enter numeric data. Designed for easy drop-in of the
Micro-Graphic panels.
Optional clear screen overlay used to protect C-more Micro-Graphic
displays from minor scratches and wear. Package contains 3 clear
screen overlays.
