Appendix A: Panel & PLC Error Code Tables
GE SNPX Protocol– PLC Error Code Tables (cont' d )
A
Panel Error Code
P499 Hex Value
0x1A0C
0x1B0C
0x1C0C
0x1D0C
0x1E0C
0x1F0C
0x200C
0x200F
0x210C
0x210F
0x220C
0x220F
0x230C
0x230F
0x240C
0x250C
0x260C
0x270C
0x280C
0x290C
PLC generated error codes for the GE 90-30, 90-70 and VersaMax SNPX protocol continue
on the next page.
A–16
PLC Errors for GE SNPX Protocol (Minor-Major) (cont'd)
Datagram area size is too small to include data for all specified point formats.
Invalid number of Control Program Names. Must be 1-8.
SNP-X Request exceeds maximum data size (1000 bytes).
Must use a smaller data length. Use multiple COMMREQs if necessary.
Invalid SNP-X communication session type.
Must be 0 for a single slave device, or 1 for multiple slave devices.
Illegal destination SNP ID specified for SNP-X slave. Must be 0-7 ASCII characters, plus a terminating null
character (00h). The Null SNP ID (eight bytes of 00h) may be used to specify any single device. The
Broadcast SNP ID (eight bytes of FFh) may be use to specify all slave devices on the serial link.
Destination SNP ID does not match SNP-X session type.
The Broadcast SNP ID is not permitted in a single-slave SNP-X session.
The Null SNP ID is not permitted in a multiple-slave SNP-X session.
Inactivity timeout (T3'). The SNP slave has not received any new SNP messages within the configured T3'
time interval.
Invalid Message Type field in a received X-Request message.
The message type of an X-Request message must be 58h = 'X'.
A Parity error has occurred on an Attach, Attach Response, or Update Real–time Datagram message.
Communications have not been established.
Invalid Next Message Type or Next Message Length field in a received X Request message. If this request
does not use a buffer (0-2 bytes of data), the Next Message Type must be zero. If this request will be
followed with a buffer message (more than 2 byte.)), the Next Message Type must be 54h = 'T', and the
Next Message Length must specify the length of the X-Buffer message. Valid X-Buffer message lengths are
9-1008 bytes (data length plus 8 bytes).
A BCC (Block Check Code) error has occurred on an Attach, Attach Response, or Update Realtime
Datagram message. Communications have not been established.
Invalid Message Type field in a received X-Buffer message.
The message type of an X-Buffer message must be 54h = 'T'.
A Framing or Overrun serial error has occurred on an Attach, Attach Response, or Update Realtime
Datagram message. Communications have not been established.
Invalid Next Message Type field in a received X-Buffer message. Since an X-Buffer message is never
followed by another message, the Next Message Type must always be zero.
An invalid SNP message type was received when an Attach, Attach Response, or Update Realtime
Datagram message was required. Communications have not been established.
An invalid next message length value was specified in an Attach, Attach Response, or Update Realtime
Datagram message. Communications have not been established.
An unexpected SNP message type was received when an Attach, Attach Response, or Update Realtime
Datagram was required. Communications have not been established.
Another Break was received while SNP slave was waiting for an Attach or Update Realtime Datagram
message.
An SNP message has been sent and retried the maximum number of times.
A maximum of two retries are permitted.
A retry is caused by a NAK from from the remote SNP device.
A received SNP message has been NAKed the maximum number of two times.
The NAKed message may be retransmitted a maximum of two times.
® ® EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
