Cables from AutomationDirect - Wiring Diagrams (cont'd)
Mitsubishi:
To PLC
8-Pin Port
Mini Din
8-pin Male
1 = RD– (RS-422)
2 = RD+ (RS-422)
3 = Sig GND
6 7
4 = SD– (RS-422)
3 4
5 = do not use
1 2
6 = do not use
7 = SD+ (RS-422)
8 = do not use
Note: Use the above wiring diagram if you need to make your own cable. We recommend Belden 8103 shielded cable or equivalent.
Omron:
To PLC
25-Pin Port
25-pin
D-sub
13 = do not use 25 = do not use
(male)
12 = do not use
24 = do not use
25
11 = do not use
23 = do not use
10 = do not use
22 = do not use
9 = do not use
21 = do not use
8 = do not use
20 = do not use
7 = Signal GND
19 = do not use
6 = do not use
18 = do not use
5 = CTS
17 = do not use
4 = RTS
3 = RXD 16 = do not use
2 = TXD
15 = do not use
1
1 = do not use
14 = do not use
Note: Use the above wiring diagram if you need to make your own cable. We recommend using 22 AWG shielded cable.
®
Mitsubishi FX Series 8-pin MINI-DIN,
RS-422A (p/n EA-MITSU-CBL-1)
Wiring Diagram
7
SD+
4
SD–
8
2
RD+
5
1
RD–
3
GND
shield
Omron Host Link (C200 Adapter, C500),
RS-232C (p/n EA-OMRON-CBL)
Wiring Diagram
2
TXD
3
RXD
7
GND
4
RTS
5
CTS
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
Chapter 6: PLC Communications
13
Term.
9
RD+ 8 = do not use
10 7 = do not use
RD–
6 = do not use
11
SD+
5 = Logic GND
12
4 = do not use
SD–
3 = do not use
5
2 = do not use
1
1 = Frame GND
3
RXD 8 = do not use
7 = do not use
2
TXD
6 = do not use
5
5 = Logic GND
4 = do not use
3 = RXD (232C)
2 = TXD (232C)
1 = Frame GND
1
shield
EA-MITSU-CBL-1
To C-more Micro-Graphic
Serial Port2
15-pin
D-sub
(male) 15 = do not use
14 = do not use
15
13 = Termination
12 = SD– (RS422)
11 = SD+ (RS422)
10 = RD– (RS422)
9 = RD+ (RS422)
1
EA-OMRON-CBL
To C-more Micro-Graphic
Serial Port2
15-pin
D-sub
15 = do not use
(male)
14 = do not use
15
13 = do not use
12 = do not use
11 = do not use
10 = do not use
9 = do not use
1
6
6–23
