GE SNPX Protocol– PLC Error Code Tables (cont' d )
Panel Error Code
P499 Hex Value
An invalid message type was received when an X-Attach Response was required when re-establishing an
0x530C existing SNP-X communication session.
Communications have not been established.
An invalid Message Type was received when an X-Attach message was required. (For an X-Attach message,
0x530F
the message type must be 58h = 'T'.)
An invalid Next Message Type value was detected in an X-Attach Response message when re-establishing
0x540C an existing SNP-X communication session.
Communications have not been established.
An invalid Next Message Type value was detected in a received X-Attach message. (For an X-Attach
0x540F
message, the Next Message Length must be zero.)
An invalid response code was detected in an X-Attach Response message when re-establishing an existing
0x550C SNP-X communication session.
Communications have not been established.
0x550F An invalid request code was detected in a received X-Attach message.
An expected X-Attach Response message was not received within the response timeout interval when re-
0x560C establishing an existing SNP-X communication session. The master has retried the X-Attach message twice
without receiving a response. Communications have not been established.
0x600C A parity error has occurred on an X-Response message.
0x600F A parity error has occurred in a received X-Request message.
0x610C A framing or overrun error has occurred on an X-Response message.
0x610F A framing or overrun error has occurred in a received X-Request message.
0x620C A BCC (Block Check Code) error has occurred on an X-Response message.
0x620F A BCC (Block Check Code) error has occurred in a received X-Request message.
0x630C An invalid message type was received when an X-Response message was required.
0x640C An invalid next message type value was detected in an X-Response message.
0x650C An invalid response code was detected in an X-Response message.
0x660C An expected X-Response message was not received within the response time.
0x700C A parity error has occurred on an Intermediate Response message.
0x700F A parity error has occurred in a received X-Buffer message.
0x710C A framing or overrun error has occurred on an Intermediate Response message.
0x710F A framing or overrun error has occurred in a received X-Buffer message.
0x720C A BCC (Block Check Code) error has occurred on an Intermediate Response message.
0x720F A BCC(Block Check Code) error has occurred in a received X-Buffer message.
0x730C An invalid message type was received when an Intermediate Response message was required.
0x730F An expected X-Buffer message was not received.
0x740C An invalid next message type value was detected in an Intermediate Response message.
0x750C An invalid response code was detected in an Intermediate Response message.
0x760C An expected Intermediate Response message was not received within the response timeout interval.
PLC generated error codes for the GE Fanuc 90-30, 90-70 and VersaMax SNPX protocol
continue on the next page.
®
PLC Errors for GE SNPX Protocol (Minor-Major) (cont'd)
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
Appendix A: Panel & PLC Error Code Tables
