Communications Port

Expansion
Connector
MODEL EA1 T4CL
MODEL EA1 T4CL
NPUT: 2-24V
NPUT: 2-24V
0 19 0 38A
0 19 0 38A C a s2
C a s2
Date code:9048
Date code:9048
MADE N CHINA
MADE N CHINA
EA1-T4CL
EA1-T4CL 094018001
094018001
PLC 15-pin serial

communications Port2

Pin
Signal
Pin
Signal
1
Frame GND
6
LE
2
TXD (232C)
7
CTS (232C)
3
RXD (232C)
8
RTS (232C)
4
Future
9
RXD+ (422/485)
5
Logic GND
10 RXD (422/485)
RS-232/422/485
®
USB Type B
Programming Port1
R**.
R**.
1
2
3
4
5
7M17
7M17
ND.CONT.EQ.
ND.CONT.EQ.
EA1-T4CL
Pin
Signal
11 TXD+ (422/485)
12
TXD (422/485)
13
Term Resistor
14
do not use
15 do not use
EA1-T6CL
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
Chapter 2: Specifications
USB Type B
Programming Port1
Expansion
Connector
R01
R01
1
2
3
4
5
MODEL:EA1-T6CL
MODEL:EA1-T6CL
INPUT:12-24V
INPUT:12-24V
6.5W C ass2
6.5W C ass2
ISTED
ISTED
8
Date code:****
Date code:****
7M17
7M17
MADE IN CHINA
MADE IN CHINA
IND.CONT EQ.
IND.CONT EQ.
15
EA1-T6CL + ser al number
EA1-T6CL + ser al number
PLC 15-pin serial
communications Port2
Pin
Signal
Pin
Signal
1
Frame GND
6
LE
2
TXD (232C)
7
CTS (232C)
3
RXD (232C)
8
RTS (232C)
4
Future
9
RXD+ (422/485)
5
Logic GND
10 RXD (422/485)
RS-232/422/485
2
1
9
Pin
Signal
11 TXD+ (422/485)
12
TXD (422/485)
13
Term Resistor
14
do not use
15 do not use
2–9
