Appendix A: Panel & PLC Error Code Tables
Siemens PPI Protocol – PLC Error Code Table
Panel Error Code
P499 Hex Value
0x0001
0x0003
0x0004
0x0005
0x0006
0x0007
0x000A
0x8000
0x8001
0x8101
0x8103
0x8104
0x8105
0x8106
0x8107
0x810A
0x8500
0x8702
0xD201
0xD202
0xD203
0xD204
0xD205
0xD206
0xD207
0xD209
0xD20E
0xD210
A–30
PLC PDU Header Errors for S7-200 PPI
Hardware Fault.
Object access not allowed.
Context not supported.
Address out of range.
Address out of range.
Write Data size mismatch.
Object does not exist.
Function being used.
Action is not allowed in current mode.
Hardware fault.
Access not allowed.
Function not supported.
Address invalid.
Data Type not supported.
Data Type is not consistent with size.
Object does not exist.
PDU Size is incorrect.
Address is invalid.
Block name syntax error.
Error with function parameter.
Error with block type.
No linked block.
Object already exists.
Object already exists.
Block already used in EPROM.
Block does not exist.
No Block does not exist.
Block number incorrect.
®
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
Description
A
