Chapter 6: PLC Communications
User Constructed Cables – Wiring Diagrams (cont'd)
Diagram 8
To PLC
9-Pin Port
9-pin
D-sub
(male)
1 = do not use
2 = TXD
3 = RXD
4 = RTS
1
5 = CTS
6
Note: Use the above wiring diagram to make your own cable. We recommend using 22 AWG shielded cable.
Diagram 9
To Peripheral
Port Cable
9-pin
D-sub
(male)
1 = do not use
2 = RXD
3 = TXD
4 = do not use
5 = Signal GND 1
Note: Use the above wiring diagram to make your own cable. We recommend using 22 AWG shielded cable.
6–28
Omron FINS (CQM1, CPM1, CPM2, C200, CJ1 & CS1)
2
6 = do not use
TXD
9
7 = do not use
3
RXD
8 = do not use
9
9 = Signal GND
SG
4
RTS
5
CTS
Omron Host Link CQM1 using
CQM1-CIF02 Peripheral Port Connecting Cable
9
3
6 = do not use
TXD
7 = do not use
2
RXD
8 = do not use
5
9 = do not use
GND
®
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
RS-232C
Wiring Diagram
3
RXD
2
TXD
5
1
shield
RS-232C
Wiring Diagram
3
RXD
2
TXD
5
1
shield
User Constructed
To C-more Micro-Graphic
Serial Port2
15-pin
D-sub
8 = do not use
15 = do not use
(male)
7 = do not use
14 = do not use
6 = do not use
13 = do not use
15
5 = Logic GND
12 = do not use
4 = do not use
11 = do not use
3 = RXD (232C)
10 = do not use
2 = TXD (232C)
9 = do not use
1
1 = Frame GND
User Constructed
To C-more Micro-Graphic
Serial Port2
15-pin
D-sub
8 = do not use
15 = do not use
(male)
7 = do not use
14 = do not use
6 = do not use
13 = do not use
15
5 = Logic GND
12 = do not use
4 = do not use
11 = do not use
3 = RXD (232C)
10 = do not use
2 = TXD (232C)
9 = do not use
1
1 = Frame GND
