Chapter 6: PLC Communications
User Constructed Cables – Wiring Diagrams (cont'd)
Diagram 16
To PLC
6-Pin Port
1 = RXD (232C)
2 = TXD (232C)
3 = Logic GND
4 = do not use
5 = do not use
6
6 = do not use
Note: Use the above wiring diagram to make your own cable. We recommend using 22 AWG shielded cable.
Diagram 17
To PLC
25-Pin Port
25-pin
D-sub
13 = do not use
(male)
12 = do not use
11 = do not use
10 = do not use
9 = do not use
8 = do not use
7 = Signal GND
6 = do not use
5 = do not use
4 = do not use
3 = RXD +
2 = TXD +
1
1 = do not use
Notes:
1. Polarities must be swapped.
2. Handshaking is turned off
3. Use the above wiring diagram if you need to make your own cable. We recommend using 8103 shielded cable or equivalent.
4. Refer to the PLC-5 Programmable Controllers User Manual Switch Setting Reference for details on switch settings to define
the controller's serial port electrical interface.
6–32
Mitsubishi Q02 / Q02H / Q06H / Q12H / Q25H Serial Driver
and QnA Serial Driver with Direct Connection to
the Serial Port on Q00 and Q01 CPU's
Mini Din
6-pin Male
2
TXD
1
RXD
5 6
3
3 4
GND
1 2
Allen Bradley PLC5 DF1
2
25 = do not use
TXD +
24 = do not use
25
3
RXD +
23 = do not use
7
22 = do not use
GND
21 = do not use
14
TXD –
20 = do not use
16
19 = do not use
RXD –
18 = do not use
17 = do not use
16 = RXD –
15 = do not use
14 = TXD –
® ®
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
RS-232C
Wiring Diagram
3
RXD
2
TXD
5
1
shield
RS-422
Wiring Diagram
10
RD –
12
SD –
5
9
RD +
11
SD +
1
shield
User Constructed
To C-more Micro-Graphic
Serial Port2
15-pin
D-sub
(male)
8 = do not use
15 = do not use
7 = do not use
14 = do not use
15
6 = donot use
13 = do not use
5 = Logic GND
12 = do not use
4 = do not use
11 = do not use
3 = RXD (232C)
10 = do not use
1
2 = TXD (232C)
9 = do not use
1 = Frame GND
User Constructed
To C-more Micro-Graphic
Serial Port2
15-pin
D-sub
8 = do not use
15 = do not use
(male)
7 = do not use
14 = do not use
15
6 = do not use
13 = do not use
5 = Logic GND
12 = SD –
4 = do not use
11 = SD +
3 = do not use
10 = RD –
2 = do not use
9 = RD +
1
1 = Frame GND
