Chapter 5: System Setup Screens

Information Menu

INFORMATION
1 Memory
2 Protocol
3 Extensions
4 Versions
5
INFORMATION
1 Memory
2 Protocol
3 Extensions
4 Versions
INFORMATION
1 Memory
2 Protocol
3 Extensions
4 Versions
INFORMATION
1 Memory
2 Protocol
3 Extensions
4 Versions
NOTE: Software and Firmware Version 3.0 or later is required with model EA1-T4CL. Version 2.5 or later is
required with model EA1-TCL. Available for free download at www.automationdirect.com.
5–6
Pressing ENT [F5] with
Memory highlighted
BAK
will show the total
memory available,
NXT
>
>
memory usage and free
>
UP
>
memory available for
DWN
the project.
ENT
ENT
Pressing ENT [F5] with
Protocol highlighted
BAK
will show the PLC
NXT
>
Protocol that has been
>
>
UP
> assigned to the panel
DWN
and the protocol
version.
ENT
ENT
Pressing ENT [F5] with
Extensions highlighted
BAK
will show if an optional
NXT keypad bezel is installed
>
>
on the panel. The
>
UP
>
example here shows the
DWN
EA-MG6-BZ2.
ENT
ENT
Pressing ENT [F5] with
Versions highlighted will
BAK
show the panel's firmware
NXT
>
and boot loader versions.*
>
>
UP
>
DWN
ENT
ENT
® EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
BAK
MEMORY
Total
3276800 Bytes
Usage
0 Bytes
Free
3276800 Bytes
BAK
PROTOCOL
Protocol Type
K Sequence
Version 2 1 0 2
BAK
EXTENSIONS
Detected Devices
BZ2
BAK
VERSIONS
Model EA1 T6CL
Firmware 3 00 0 0
Boot Loader
