Available PLC Protocols
The panel can also be connected to more than one PLC by using RS-422 or RS-485 wired in
a multi-drop configuration. See the example wiring diagrams at the end of this chapter for
details.
If you have difficulty determining whether the particular PLC and/or protocol you are using
will work with C-more Micro-Graphic panels, please contact our technical support group at
770-844-4200.
®
Serial - port2 only
AutomationDirect Productivity Series
AutomationDirect CLICK
AutomationDirect K-sequence
AutomationDirect DirectNET
AutomationDirect Modbus
AutomationDirect SOLO
AutomationDirect GS Drives
Modicon Modbus RTU
Entivity Modbus RTU
Allen-Bradley DF1 Full Duplex
Allen-Bradley DF1 Half Duplex
Allen-Bradley PLC5 DF1
Allen-Bradley DH485
GE SNPX (90/30, 90/70, Micro 90, VersaMax Micro)
Omron Host Link (C200 Adapter, C500)
Omron FINS Serial (CJ1, CS1)
Siemens PPI (S7-200 CPU)
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
Chapter 6: PLC Communications
PLC Drivers
Mitsubishi FX
Mitsubishi Q, QnA
