EA1-T4CL Panel Dimensions

Panel Dimensions
Units: Inches [mm]
3.58
[91.0]
Enclosure Thickness
®
2.04
1.81 1.25
[51.7]
[31.8]
[45.9]
.34
[8.7]
4.36
[110.8]
ENCLOSURE MOUNTING
THICKNESS RANGE
0.04" - 0.2" [1 - 5mm]
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
Chapter 2: Specifications
3.58
[91.0]
MOUNTING CLIP
(4) places
GASKET
4.31
[109.5]
Mounting Clip Screw Torque
MOUNTING CLIP
SCREW TORQUE RANGE
21 - 28 oz-in [0.15-0.2 Nm]
MODEL EA1-T4CL
INPUT:12 24V 0 19 0 38A Cla s2
Da e code 9048
MADE IN CHINA
EA1 T4CL 094018001
2
R**. 1 3 5
7M17
ND CONT.EQ.
2–7
