Chapter 2: Specifications
EA1-T6CL Panel Dimensions
Panel Dimensions
2
Units: Inches [mm]
4.770
[121.3]
2–8
2.13
1.453
1.689
[54.1]
[36.9]
[42.9]
.236
[6.0]
Units: Inches [mm]
5.331
[135.4]
Enclosure Thickness
ENCLOSURE MOUNTING
THICKNESS RANGE
0.04" - 0.2" [1 - 5mm]
®
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
6.295
[159.9]
6.850
[174.0]
Mounting Clip Screw Torque
MOUNTING CLIP
SCREW TORQUE RANGE
21 - 28 oz-in [0.15-0.2 Nm]
MOUNTING CLIP
(4) places
GASKET
