SER MGT port – Rear Panel
FIGURE:
This port is needed to set up the NET MGT port.
When connecting a DB-9 cable, use an RJ-45 to DB-9 adapter to perform the
crossovers given for each connector.
Note – Use the SER MGT port only for server management. This port is the default
connection between the SP and a terminal or a computer.
Caution – Do not attach a modem to this port.
Related Information
"Connect the NET MGT Port Cable" on page 45
"Connecting Cables" on page 39

▼ Connect the NET MGT Port Cable

The NET MGT port is located just to the right of the SER MGT port on the rear panel.
Connect a Category 5 cable from the NET MGT port to your network switch or
hub.

Connecting Cables

45
