Related Information
"Rack Compatibility" on page 19
"Slide Rail Assemblies" on page 22
"Install the Slide Rail Assemblies" on page 25
"Install the CMA" on page 31
"Verify Correct Operation of the Slide Rails and the CMA" on page 36

(Optional) Installing the CMA

"Install the CMA" on page 31
"Verify Correct Operation of the Slide Rails and the CMA" on page 36

▼ Install the CMA

Caution – Support the CMA during this installation. Do not allow the assembly to
hang by its own weight until it is secured by all three attachment points.
1. Remove the tape from the CMA rail extension (on the left of the CMA) and
remove the CMA rail extension.
2. Attach the CMA rail extension to rear left slide rail.
At the rear of the rack, plug the CMA rail extension into the end of the left sliding
rail assembly. The tab at the front of the rail extension clicks into place.
Installing the Server
31
