15.4

Attach adjustable letter guide to feeder / sealer

Wire
spring
Pin
On both sides, the adjustable letter guide
Clips
is provided with clips for locking the bar.
The two slots in the front edge of the lug
will hold the wire spring on the bar.
Slots
How to insert the letter guide:
• Pull out the bar for adjusting the letter
guide.
• Insert the letter guide so that the wire
spring (in the bar) engages into the two
narrow slots on the front edge of the
lug.
• Tilt the letter guide downward (in the
direction of the letter receiving tray).
Place the two clips on the pins at the
bar with slight pressure and lock into
place.
• Insert the bar.
You can avoid the letter guide being
pulled off:
– For adjusting the letter guide, always
hold in the recessed grip at the bar.
– Always set the letter guide so that a
clearance of about 0.1" (2 to 3 mm) is
left.
Troubleshooting 155
