FP Mailing Solutions optimail 30 Manual

Connecting to a network with a universal link box (ulb)
Hide thumbs Also See for optimail 30:

Advertisement

Quick Links

Download this manual
Connecting the optimail™ 30 to a Network with a
Universal Link Box (ULB)
© 2009 FP Mailing Solutions. All rights reserved.
© 2009 FP Mailing Solutions. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the optimail 30 and is the answer not in the manual?

Questions and answers

Related Manuals for FP Mailing Solutions optimail 30

Summary of Contents for FP Mailing Solutions optimail 30

  • Page 1 Connecting the optimail™ 30 to a Network with a Universal Link Box (ULB) © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 2 Standard gateway= A gateway makes it possible to link computer networks, which communicate in different computer languages, to communicate with each other. Source: Wikipedia © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 3 Overview General installation Option 1 DHCP all Automatic Option 2 DHCP with a Proxy server Network Administrator configuration only © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 4 General installation Click here to go back to the overview. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.

  • Page 5: General Installation

    The display will prompt to continue by the following these steps: Menu -> 2x Arrow down -> Modem and Telephone numbers -> adjust modem parameter Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 6 Please select the Universal Link Box, then the unit will try to make a standard connection to the network. Click on the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 7 General installation In most cases the automatic connection with a standard configuration will fail, so just press enter to continue. Click the Highlighted Enter key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 8 Lets get started click on Option 1 below: Option 1 DHCP all Automatic Click here to go back to the overview. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 9 Option 1 DHCP all Automatic In this menu a switch between static IP address and DHCP is possible. Choose DHCP option. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 10 Option 1 DHCP all Automatic The display will now show DHCP, press continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 11 Option 1 DHCP all automatic The option for automatic DNS configuration is displayed, so please click on continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 12 Option 2 DHCP all automatic The Proxy-Server configuration is allready turned off, so just click on continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 13 The automatic configuration is now displayed in the screen. To confirm click the save soft-key. The connection to your network is now completed. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 14 The postage machine is now configured for DHCP and should be connected to the network. Please try to download postage. Click the Highlighted Enter key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 15 Click on Option 2 to configure DHCP with a Proxy-Server. Option 2 DHCP with Proxy-Server Click here to go back to the Overview. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 16 In this menu there is the option to switch between static IP address and DHCP (Dynamic Host Connection Protocal), please choose DHCP. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 17 Option 2 DHCP with Proxy server The display will now show DHCP, press continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 18 Option 2 DHCP with Proxy server The option for automatic DNS configuration is displayed, so please click on continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 19 Option 2 DHCP with Proxy server The display will show the Proxy-Server configuration turned off. Turn on the Proxy- sever configuration. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 20 Option 2 DHCP with Proxy-server The Proxy-Server configuration is turned on , please click on continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 21 Option 2 DHCP with Proxy Obtain the proxy address form your network administrator, or from any PC on the network. Click on continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 22 To input the new proxy settings, there must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: Example: 10.128.3.3 => 010.128.003.003 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 23 If the Proxy-Port is not known, then contact the network administrator, or check the network settings in the PC. Enter the Proxy-port and press continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 24 Option 2 DHCP with Proxy-server If no Proxy-Authentication is required, then select off. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 25 Option 2 DHCP with Proxy-server The display will now show the Proxy-authentication turned off. Press continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 26 The display will now show the changes made. Please click on Save. The system will attempt to connect to the network, and a test will be performed. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 27 Press enter to complete the configuration. The machine is now ready to download postage. Click the Highlighted Enter- key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 28 Option 3 Static IP-Address Without Proxy-server (Network Administrator) Option 4 Static IP-Address with Proxy-server (Network Administrator) Option 5 Static IP-Address with Proxy and Authentication (Network Administrator) © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 29 Static IP address. Option 3 Static IP-Address without Proxy-server (Network Administrator) Click here to go back to the Network Administrator. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 30 Subnet (gateway) – address. Please contact the network administrator for this information. “Static IP-address” is displayed, press next to continue. Click on the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 31 -The Subnet (Subnet mask) is displayed -The default Gateway is displayed -The DHCP address & DNS address are both displayed. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 32 To enter the new Static IP-address, there must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: Example: 193.29.244.123 => 193.029.244.123 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 33 Subnet Mask, there must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: Example: 255.255.255.0 => 255.255.255.000 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 34 “0 “. See the example below: Example: 193.29.244.1 => 193.029.244.001 Click on the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 35 Select the Manual option for DNS configuration. If necessary additional information on DNS configuration can be obtained from the network administrator. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 36 Option 3 Static IP-Address without Proxy The Manual option for DNS configuration is displayed, please select continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 37 There must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example: Example: 192.168.2.31 => 192.168.002.031 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 38 There must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example: Example: 192.168.2.30 => 192.168.002.030 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 39 Option 3 Static IP-Address without Proxy The Proxy-server configuration is switched on, please select off. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 40 Option 3 Static IP-Address without Proxy The display shows Proxy-server is switched off, please select continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 41 The display will now show the changes made. Please click on Save. The system will attempt to connect to the network, and a test will be performed. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 42 Press enter to complete the configuration. The machine is now ready to download postage. Click the Highlighted Enter key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 43 Please select Option 4 below to continue: Option 4 Static IP-Address with Proxy-server (Network administrator) Click here to go back to the Network Administrator. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 44 To proceed further it is necessary to have the following information: IP address, Subnet (gateway) – address. Please contact the network administrator for this information. “Static IP-address” is displayed, press continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 45 -The Subnet (Subnet mask) is displayed -The default Gateway is displayed -The DHCP address & DNS address are both displayed. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 46 To enter the new Static IP-address, there must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: 193.29.244.123 => 193.029.244.123 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 47 Subnet Mask, there must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: Example: 255.255.255.0 => 255.255.255.000 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 48 To enter the new Gateway address, there must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: Example: 193.29.244.1 => 193.029.244.001 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 49 Select the Manual option for DNS configuration. If necessary additional information on DNS configuration can be obtained from the network administrator. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 50 Option 4 Static IP-address with Proxy-server The Manual option for DNS configuration is displayed, please select continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 51 There must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example: Example: 192.168.2.31 => 192.168.002.031 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 52 There must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example: Example: 192.168.2.30 => 192.168.002.030 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 53 Option 4 Static IP-address with Proxy-server The Proxy-server configuration is switched on, please select continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 54 PC running Windows XP. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 55 To input the new proxy settings, there must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: Example: : 10.128.3.3 => 010.128.003.003 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 56 Option 4 Static IP-address with Proxy-server Enter the Proxy-port and press continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 57 Option 4 Static IP-address with Proxy-server If Proxy-Authentication is not used , select “OFF“ to continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 58 Option 4 Static IP-address with Proxy-server Proxy-Authentication is switched off, select continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 59 The display will now show the changes made. Please click on Save. The system will attempt to connect to the network, and a test will be performed. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 60 Press enter to complete the configuration. The machine is now ready to download postage. Click the Highlighted Enter key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 61 Please select Option 5 below to continue: Option 5 Static IP-Adress with Proxy and Authentication (Network administrator) Click here to go back to the Network Administrator. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 62 To proceed further it is necessary to have the following information: IP address, Subnet (gateway) – address. Please contact the network administrator for this information. “Static IP-address” is displayed, press continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 63 -The Subnet (Subnet mask) is displayed -The default Gateway is displayed -The DHCP address & DNS address are both displayed. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 64 To enter the new Static IP-address, there must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: Example: 193.29.244.123 => 193.029.244.123 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 65 Subnet Mask, there must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: Example: : 255.255.255.0 => 255.255.255.000 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 66 “0 “. See the example below: Example : 193.29.244.1 => 193.029.244.001 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 67 Select the Manual option for DNS configuration. If necessary additional information on DNS configuration can be obtained from the network administrator. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 68 Option 5 Static IP-Address with Proxy-Server and Authentication The Manual option for DNS configuration is displayed, please select continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 69 There must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: Example : 192.168.2.31 => 192.168.002.031 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 70 There must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: Example : 192.168.2.30 => 192.168.002.030 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 71 Option 5 Static IP-Address with Proxy-Server and Authentication The Proxy-server configuration is switched on, please select continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 72 Enter the Proxy-address, and select continue. If the Proxy-address is not known, please contact the network administrator or veiw the network information from any PC running Windows XP. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 73 To input the new proxy settings, there must be 3-digit per block, if necessary fill up the empty space with “0 “. See the example below: Example: : 10.128.3.3 => 010.128.003.003 Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 74 Option 5 Static IP-Address with Proxy-Server and Authentication Enter the Proxy-port and press continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 75 Option 5 Static IP-Address with Proxy-Server and Authentication Proxy-Authentication is turned “on” in the display, select continue. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 76 Now enter the Proxy User Name using the numeric keypad. Then select continue. See the example User Name below: Example User Name: z.B. PAUL. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 77 Now enter the Proxy-Password, and select continue. For further information please ask a network administrator. Please see the example below: Example: z.B. saeitz Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 78 The display will now show the changes made. Please click on Save. The system will attempt to connect to the network, and a test will be performed. Click the Highlighted Soft-key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
  • Page 79 Authentication, and should connect to the network. Press enter to complete the configuration. The machine is now ready to download postage. Click the Highlighted Enter key. © 2009 FP Mailing Solutions. All rights reserved. © 2009 FP Mailing Solutions. All rights reserved.
