Yamaha CL5 Reference Manual

Dgital mixing console yamaha cl5; cl3; cl1
Hide thumbs

Advertisement

How to Use This Reference Manual

The CL5/CL3/CL1 Reference Manual (this document) allows you to
search for terms and take advantage of links in the text.
Searching for terms
To search for a term, use the search function of the software you're using
to view this document.
If you're using Adobe Reader, enter the term in the search box and press
the <Enter> key of your computer keyboard to search for occurrences of
that term.
Displaying the next/previous view
If you're using Adobe Reader, you can jump to the previous/next view in
your viewing history. This is a convenient way to jump back to the
previous page after you've used a link to jump to a different page.
Reference Manual
Using the Function Tree
A function tree for the CL5/CL3/CL1 is provided on
page 4
and
following. You can use this function tree to find the page that explains
an on-screen display or function.
EN
