Using the Matrox PCIe host adapters

For MXO2 LE to be detected on a Mac desktop system, power must be supplied
to MXO2 LE (see
to your computer before starting up your system.
¡ Important Do not disconnect the Matrox PCIe cable from the adapter, or
MXO2 LE, when your Mac system is running. To safely remove the Matrox PCIe
host Expresscard/34 adapter, see
adapter"
Chapter 5, Connecting External Devices to Matrox MXO2 LE
"Powering MXO2 LE"
on page 8.
PCIe cable
Matrox PCIe
host adapter
on page 32), and it must be connected
"Removing your PCIe host ExpressCard/34
²Caution To ensure functionality
and avoid damaging the PCIe cable
or host connector, you must connect
the PCIe cable as shown in
"Ensuring proper PCIe cable
connection" on page 34.
Matrox PCIe host
ExpressCard/34
adapter
OR
To your laptop's ExpressCard/34
slot (see "Installing your PCIe host
ExpressCard/34 adapter (for
laptops)" on page 7).
MXO2 LE
(side view)
