Select the H.264 level that you want to be used to encode your video.
$
H.264 level
2.0
3.0
3.1
4.0
4.1
4.2
Select the Noise filter level that will be applied to your video before
$
encoding. Increasing the noise filter level reduces the amount of high
frequencies in your source video by softening the high-detail portions of
your video. Since high frequencies require more bits to encode, increasing
the noise filter level leaves more bits available for the encoding of other
frames, which can improve the overall quality of your encoded video.
However, if you lose too much detail in your encoded video you may need
to decrease the noise filter level.
Click OK to save and close the Matrox MAX H.264 Codec Settings
6
dialog.
In the Export Settings dialog, in the Video pane, under Bitrate Settings ,
7
enable the Limit data rate to option and enter a value if you're using the
CAVLC entropy coding algorithm (see step 5). If using CABAC, you can
enable or disable this option.
8 For optimal results when encoding using the Matrox MAX H.264 codec, in
the Video pane, under Basic Video Settings , select Progressive from the
Field Order list.
Specify any other export settings as desired. For detailed information on
9
Media Encoder settings, see your Media Encoder documentation.
¦ Note
To export a clip for use with Apple iPad, iPod or iPhone devices, you
must select AAC as the Audio Codec .
In the Export Settings dialog, under Export Settings , click the Save
10
Preset button next to the Preset list.
Type a descriptive name for your preset, and then click OK .
11
Export the file as you would normally.
12
Maximum
Maximum
Frame rate
Frame size
(fps)
352 ×288 29.97
720 ×576 29.97
1280×720 29.97
1920×1080 29.97
1920×1080 29.97
1920×1080 59.94
Using Adobe Premiere Pro or Media Encoder
Maximum
Data rate
(Mb/s)
2
10
14
20
50
50
