Connecting to Matrox MXO2 Mini

²Caution To ensure functionality and avoid
damaging the PCIe cable or host connector,
you must connect the PCIe cable as shown in
"Ensuring proper PCIe cable connection"
page 44.
on
Matrox MXO2 Dock
Connecting MXO2 Dock to your MXO2 system
MXO2 Mini
PCIe cable
Thunderbolt cable
(Not included. A
Thunderbolt cable is
required to connect Matrox
MXO2 Dock to your
computer.)
To your computer's
Thunderbolt port.
191
