area.
¦ Note When Out is selected, the duration is calculated based on your
selected In and Out points. When Duration is selected, the Out point is
calculated based on your specified In point and duration.
Click Export to start the export to tape.
12
¦ Note The Export button is not available when the tape/recorder is in Record
Inhibit mode, when there is no tape in the recorder, or when an invalid
connection is detected.

Using the Matrox MPEG-2 I-frame codec

The Matrox MPEG-2 I-frame codec is a full-raster HD codec that gets installed
automatically when you install your MXO2 software. It is included primarily for
users who do not have a full-raster HD codec installed on their system.
To capture SD/HD video using the Matrox MPEG-2 I-frame codec, the MXO2
software must be installed on your system, and the MXO2 hardware must be
connected.
If the captured video will be played back on another system, the Matrox MPEG-2
I-frame codec must be installed on that system as well. You can download the
Matrox MPEG-2 I-frame codec for playback on other Mac systems from the
Download section of our Support website at www.matrox.com/video/support.
° To configure the Matrox MPEG-2 I-frame codec:
The default settings for the Matrox MPEG-2 I-frame codec provide good results
for most applications. We recommend that you change these settings only when
needed for special purposes.
) at any time to set the duration back to the duration of the work
Working with Adobe Premiere Pro
105
