Working with Adobe SpeedGrade

You can output video played back in Adobe SpeedGrade on the Matrox MXO2
video outputs to preview your clips on your video monitor. You can also choose
to output audio played back in Adobe SpeedGrade on your Matrox MXO2
hardware.
For detailed information about using Adobe SpeedGrade, see your Adobe
SpeedGrade documentation.
° To specify your playback settings for use with Matrox MXO2:
In Adobe SpeedGrade, click Preferences (
1
window.
In the Preferences dialog, click Playback and set the Base frame rate for
2
the playback, such as 29.97 .
Click Display and select Enable under Mercury Transmit .
3
From the Device list, select Matrox Player .
4
From the Resolution list, select the resolution for playback, such as 1080p
5
(1920 x 1080)
Click Setup and select the bit depth for your video output (8-bit or 10-bit).
6
Chapter 9, Using Matrox MXO2 with Supported Programs
.
) at the top left of the
