TECHNICAL DATA & SERVICE MANUAL
R410A Models
Model No.
Indoor Units
Indoor
Type
Units Type
U1
4-Way Cassette
S-36PU1E5A S-45PU1E5A S-50PU1E5A S-60PU1E5A S-71PU1E5A S-100PU1E5A S-125PU1E5A S-140PU1E5A
T2
Ceiling
S-36PT2E5A S-45PT2E5A S-50PT2E5A S-60PT2E5A S-71PT2E5A S-100PT2E5A
K1
Wall Mounted
S-36PK1E5A S-45PK1E5A S-50PK1E5A S-60PK1E5A S-71PK1E5A
Low Silhouette
F1
S-36PF1E5A S-45PF1E5A S-50PF1E5A S-60PF1E5A S-71PF1E5A S-100PF1E5A S-125PF1E5A S-140PF1E5A
Ducted
N1
Ducted
S-36PN1E5A S-45PN1E5A S-50PN1E5A S-60PN1E5A S-71PN1E5A S-100PN1E5A S-125PN1E5A S-140PN1E5A
Outdoor Units
Type
Outdoor Units Type
Single Split (1-phase)
PE1
Single Split (3-phase)
Single Split (1-phase)
PEY1
Single Split (3-phase)
85464849331000
Indoor Unit
4-Way Cassette
Ceiling
Wall Mounted
Low Silhouette Ducted
Ducted
36
45
50
U-50PE1E5
50
60
71
60
71
U-60PE1E5A U-71PE1E5A U-100PE1E5A U-125PE1E5A U-140PE1E5A
U-71PE1E8A U-100PE1E8A U-125PE1E8A U-140PE1E8A
U-60PEY1E5
U-71PEY1E5 U-100PEY1E5 U-125PEY1E5
Order No. SBPAC1403009CE
Outdoor Unit
100
125
S-125PT2E5A S-140PT2E5A
S-100PK1E5A
100
125
U-100PEY1E8 U-125PEY1E8
REFERENCE NO.
140
140
U-140PEY1E8
SM830231-00
