B.2 Twisted-Pair Ethernet Connector
8
FIGURE B-2
TABLE B-2
Pin
1
2
3
4
B.3 ISDN Terminal Endpoint Connector
8
FIGURE B-3
TABLE B-3
Pin
1
2
3
4
1
Twisted-Pair Ethernet Connector
Pinout for Twisted-Pair Ethernet Connector
Description Pin
Transmit Data + 5
Transmit Data - 6
Receive Data + 7
N/C 8
1
ISDN Terminal Endpoint Connector
Pinout for ISDN Terminal Endpoint Connector
Description Pin
PS1 5
PS1- 6
Transmit Data + 7
Receive Data + 8
Description
N/C
Receive Data -
N/C
N/C
Description
Receive Data -
Transmit Data -
PS2-
PS2
Appendix B System Connectors B-3
