Figure 11-5 Vsimm Slot Location - Sun Microsystems SPARC classic Service Manual

FIGURE 11-5
3. Place an antistatic mat, shiny side up, next to the system unit.
The mat is supplied with the replacement VSIMM.
4. Remove the faulty VSIMM.
Grasp the VSIMM at its top corners and carefully wiggle it free from its connector
(see
FIGURE 11-6
5. Place the VSIMM on the antistatic mat.
11-8 SPARCclassic/SPARCclassic X/SPARCstation LX Service Manual • November 1993
VSIMM slot
VSIMM Slot Location
). Be careful not to touch any of the components on the VSIMM.
