Security loop
System I/O board
UNIT BOTTOM
FIGURE 12-2
Exploded View of the Unit Bottom
NVRAM/TOD
Diskette drive
data cable
Hard drive data cable
Internal speaker and
power LED assembly
Main logic board
extractor lever
Chapter 12
Illustrated Parts Breakdown
Keyboard soft
power-on cable
Main logic
power cable
12-3
