Pull tab
Hard drive
power cable
Hard drive
data cable
Hard disk drive
Disk drive
mounting bracket
Drive screw holes
Disk drive bracket
without grommet
FIGURE 9-1
9.1.2

Preparing a Hard Drive for Installation

To prepare a hard drive for installation, you must first verify that the SCSI ID
jumpers on the drive controller board are set correctly. After you are satisfied that
the SCSI ID jumpers are correct, follow the directions later in the chapter for
installing the hard drive.
Diskette drive
data cable
Pull tab
Shoulder screw
Hard Disk Drive in the Disk Drive Bracket
Keyboard soft
power-on cable
Main logic
power cable
UNIT TOP
Disk drive bracket
with grommet
Chapter 9 Storage Devices
Cable
management
guides
Power supply
9-3
