Figure 3-4 Arrangement Of The Type-5 Keyboard Leds - Sun Microsystems SPARC classic Service Manual

Caps Lock LED
(UNIX keyboard)
Arrangement of the Type-5 Keyboard LEDs
FIGURE 3-4
If the Caps Lock key fails to flash on and off after you have pressed and held the
Stop-d keys when you power on the system, POST failed. See Section 4.2.2 "System
Board Test" for troubleshooting information.
Caps Lock
(U.S. keyboard)
Chapter 3
Scroll Lock Num Lock
LED LED
Compose
LED
Power-On Self-Test (POST) 3-9
