A
A P P E N D I X
System Specifications
This appendix contains system specifications, including input power requirements,
environmental requirements, physical specifications, and regulatory compliance
information. All specifications are applicable to both SPARCclassic and
SPARCstation LX systems. Not all specifications will be applicable to the
SPARCclassic X terminal, which does not come equipped with a diskette drive or
hard disk drive.
Section A.1 "Input Power Requirements"
Section A.2 "Environmental Requirements"
Section A.3 "Physical Specifications"
Section A.4 "Regulatory Compliance"
A.1 Input Power Requirements
TABLE A-1
TABLE A-1
Parameter
Nominal Frequencies
Nominal Voltage Range
Maximum Current AC RMS
AC Operating Range
Maximum VA Rating
Maximum Power Consumption
Maximum Heat Output
lists the input power requirements for the system unit.
Input Power Requirements and Power Dissipation
1
*
Specification
50 Hz or 60 Hz nominal
100-120 Vac or 200-240 Vac
(100-240 Vac Auto)
2 A @ 100-120 Vac, 1 A @ 200-240 Vac
87-264 Vrms, 47-63 Hz
153.8 VA
107.7 Watts
367.5 BTU/hr
A-1
