FIGURE 11-9
TABLE 11-1
Total
Memory
8 MB
8 MB
8 MB
12 MB
12 MB
12 MB
16 MB
16 MB
20 MB
24 MB
32 MB
36 MB
36 MB
40 MB
40 MB
44 MB
11-12 SPARCclassic/SPARCclassic X/SPARCstation LX Service Manual • November 1993
DSIMM Slot Locations
Memory Configuration Matrix—SPARCclassic X Terminal
Slot Slot
U0304 U0301
1 MB 1 MB
2 MB 2 MB
4 MB —
1 MB 1 MB
2 MB 4 MB
2 MB 2 MB
2 MB 2 MB
4 MB 4 MB
2 MB 4 MB
4 MB 4 MB
16 MB —
1 MB 1 MB
2 MB 16 MB
2 MB 2 MB
4 MB 16 MB
2 MB 4 MB
SIMM slot U0401
SIMM slot U0302
SIMM slot U0303
SIMM slot U0402
SIMM slot U0301
SIMM slot U0304
Slot Slot
U0402 U0303
2 MB 1 MB
— 2 MB
— 4 MB
4 MB 1 MB
— 2 MB
2 MB 2 MB
4 MB 2 MB
— 4 MB
4 MB 2 MB
4 MB 4 MB
— 16 MB
16 MB 1 MB
— 2 MB
16 MB 2 MB
— 4 MB
16 MB 2 MB
Bank 3
Bank 2
Bank 1
Bank 3
Bank 2
Bank 1
Slot Slot
U0302 U0401
1 MB 2 MB
2 MB —
— —
1 MB 4 MB
4 MB —
2 MB 2 MB
2 MB 4 MB
4 MB —
4 MB 4 MB
4 MB 4 MB
— —
1 MB 16 MB
16 MB —
2 MB 16 MB
16 MB —
4 MB 16 MB
