2- Description and connection of router

2.1.2 LEDs and buttons

2.1.2.1 On the front panel
The following table describes the meaning of the LEDs on the front panel of the router:
LED
Off
Green
Power
Red
Green steady
Green blinking
ADSL
Off
Internet
Green steady
Green blinking
Red
Off
Green steady
LAN x
(1 to 4)
Green blinking
Off
Green steady
WLAN
Green blinking
Page 2-4
Status
Power Off
Power On
Router in rescue mode
ADSL Up
• ADSL Synchronisation in progress
or
• down
• Power Off
or
• The Internet account must be configured
or
• Bridge mode
The Internet account is configured
Tx/Rx traffic
Invalid or unauthorised Internet account
No link detected on the Ethernet port
Ethernet port has detected a link with 100 Mbps device
Tx/Rx traffic at 100 Mbps
Wi-Fi deactivated
Wi-Fi activated
Wi-Fi Tx/Rx
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Meaning
F@ST 2704R Reference Manual - 253526032-A
