Security - SAGEMCOM F@ST 2704R Reference Manual

6.4.6 Security

6.4.6.1 IP Filtering
Outgoing
Object: This menu is used to create outgoing IP filters to refuse data from the LAN to the WAN and list the
existing outgoing IP filters.
By default, all the outgoing data is accepted.
• In the Advanced Setup menu, select Security > IP Filtering > Outgoing.
The following screen opens:
Filter Name
IP Version
Protocol
SrcIP/ PrefixLength
Source Port
DstIP/ PrefixLength
DstPort
Remove
F@ST 2704R Reference Manual - 253526032-A
Field
Name of the filter.
IP version used.
Transport protocol.
"Source" address (your computer, for example) and
associated subnet mask.
Source port.
"Destination" address (a machine on the Internet, for
example) and associated subnet mask.
Destination port.
Check the box and click on the [Remove] button to
remove the object from this list.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
6- Advanced parameters
Meaning
Page 6-57
