4- Configuration of network parameters

4.2 Status of the DHCP server

To obtain the status of the DHCP server:
1. Open your browser.
2. Enter the router's IP address (by default http://192.168.1.1) or enter the following URL
http://myrouter
3. In the login screen that appears, enter "admin" in the "User Name" field and "etdm" in the "Password"
field (see note).
Note
The User name and Password are provided on the label located behind the router.
4. Click on the OK button to validate.
5. From the welcome screen, select Management then Advanced.
6. Select Advanced Setup menu, then select the LAN menu.
The following screen appears:
Field
IP Address
Subnet Mask
Start IP Address
End IP Address
Leased Time (hour)
Page 4-4
Description
Displays the sub-network address.
Displays the sub-network mask of the IP network.
Displays the first address attributed by the DHCP server.
Note: This IP address must belong to the same
sub-network as that of the local network.
Displays the last address attributed by the DHCP server.
Note: This IP address must belong to the same
sub-network as that of the local network.
Displays the period (in hours) for obtaining an IP address
for a terminal.
Sagemcom Broadband SAS document.
F@ST 2704R
Reproduction and disclosure prohibited
Display
192.168.1.1
255.255.255.0
192.168.1.2
192.168.1.254
24
Reference Manual - 253526032-A
