SAGEMCOM F@ST 2704R Reference Manual page 166

6- Advanced parameters
Field
RX Chain Power
Save Quiet Time
RX Chain Power
Save PPS
Radio Power
Save
Radio Power
Save Quiet Time
Radio Power
Save PPS
TM
54g Rate
Multicast Rate
Basic Rate
Fragmentation
threshold
RTS Threshold
DTIM Interval
Page 6-116
Action/Meaning
The number of seconds the traffic must be below the PPS
value below before the Rx Chain Power Save feature
activates itself.
The maximum number of packets per seconds that can be
processed by the WLAN interface for a duration of Quiet
Time, described above, before the Rx Chain Power Save
feature activates itself.
Enabling this feature turns off one of the Transmit chains.
The number of seconds the traffic must be below the PPS
value below before the Radio Chain Power Save feature
activates itself.
The maximum number of packets per seconds that can be
processed by the WLAN interface for a duration of Quiet
Time, described above, before the Radio Chain Power Save
feature activates itself.
In the scroll down list, select the transmission rate at which
the information (data or video) will be transmitted or received
on your wireless network (Auto, 1, 2, 5.5, 6, 9, 11, 12, 18, 24,
36, 48 or 54 Mbps).
Note: If you select "Auto", the information will be transmitted
at an optimised rate which takes account of the
transmission constraints.
From the scroll down list, select the transmission rate at
which the "Multicast" packets are transmitted (Auto, 1, 2, 5.5,
6, 9, 11, 12, 18, 24, 36, 48 or 54 Mbps).
Note: If you select "Auto", the information will be transmitted
at an optimised rate which takes account of the
transmission constraints.
Video conferencing and teleconferencing are "Multicast"
applications.
From the scroll down list, select the basic rate at which the
information will be transmitted or received over your wireless
network (Default, All, 1 & 2 Mbps or 1 & 2 & 5.5 & 6 & 11 &
12 & 24 Mbps).
This packet fragmentation mechanism is used to limit errors
and repetitions.
It is recommended not to reduce the packet size too much to
avoid reducing the bandwidth.
Enter a threshold value (in bytes) between 256 and 2347.
The RTS/CTS protocol (Request To Send / Clear To Send) is
used to reduce the probability of collisions between stations.
Note: As packet size is set by default to 2346, the RTS/CTS
protocol is inhibited as its value is set by default to
2347.
Enter a threshold value (in bytes) between 1 and 2347.
Enter a time interval value between two beacon signals
which shows the activity of the wireless.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Default
value
Auto
Auto
Default
2346
2347
F@ST 2704R Reference Manual - 253526032-A
10
10
Off
10
1
1
