SAGEMCOM F@ST 2704R Reference Manual page 128

6- Advanced parameters
Add
• Click on the Add button to display the following screen:
Field
Policy Name
Physical LAN port
Source IP
Use Interface
Default Gateway IP
Page 6-78
Enter the policy name.
Select Blank or the interface of your choice (eth01-04 or wlan0)
from the drop-down list.
Enter a source IP address.
Select the interface you want to use from the drop-down list
(Internet.10/ppp0.1 for example).
Enter the default gateway IP address.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Action
F@ST 2704R Reference Manual - 253526032-A
