6.4.9.2 Static Route
Object: This menu is used to add a static route.
• In the Advanced Setup menu, select Routing then select Static Route.
The following screen opens:
IP Version
DstIP/ PrefixLength
Gateway
Interface
Metric
Remove
F@ST 2704R Reference Manual - 253526032-A
Field
Internet Protocol version 4.
"Destination" address (a machine on the Internet, for
example) and associated subnet mask.
Default gateway of the remote network.
Remote network interface.
Number of hops to reach a distant terminal from the
Residential Gateway.
Check this box and click on the [Remove] button to
remove the selected object from the list.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
6- Advanced parameters
Meaning
Page 6-75
