Model F@st™2864 Router User's Guide

LEDs / Push Buttons

The figures below show the LEDs and push buttons from the side and front of the F@st™2864.
The figure below defines the icons for the LEDs and push buttons on the F@st™2864.
F@st™2864 – Front Panel LED and Button Labelling
LEDs
st
1 LED
nd
2 LED
rd
3 LED
4 th LED
th
5 LED
6 th LED
th
7 LED
Note that the rear Ethernet connectors contain yellow (10/100Mbps) and green (1000Mbps) LEDs.
Side
Power
HPNA
WAN
Internet
TV
Wireless
WPS
6
Buttons
st
1 Button N/A
2 nd Button
rd
3 Button
Physical Installation
Front
N/A
Wireless
WPS
