SAGEMCOM F@ST 2704R Reference Manual page 74

6- Advanced parameters
6.4.2.2 Ethernet over ATM – PPP over Ethernet (PPPoE)
• Select the WAN service type PPP over Ethernet (PPPoE).
Field
Enter Service
Description
Enter 802.1P Priority
Enter 802.1Q VLAN ID
Network Protocal
Selection
a. These values only appear if the WAN service is configured over a DSL ATM interface using VLAN MUX
Mode.
Page 6-24
Displays the name of the service being configured. This
name, which is allocated automatically, is made up as
follows: Protocol_VPI_ Index _ VCI
For example: pppoe_eth0.
Note: You may enter another service name.
Enter a value for the 802.1P Priority. This value is
a
between 0 and 7.
Enter a value for the 802.1QVLAN ID. This value is
a.
between 0 and 4094.
Select the type of network from the drop-down list:
• IPv4 Only
• IPv4&IPv6 (Dual Stack)
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Action
F@ST 2704R Reference Manual - 253526032-A
Default value
pppoe_eth0
-1
-1
IPv4 Only
