SAGEMCOM F@ST 2704R Reference Manual page 99

Field
Interface Address
Enable DHCPv6
Server
a
Stateless
a
Stateful
Enable RADVD
Enable ULA Prefix
b
Advertisement
Randomly
b
Generate
Statically Configure
Enable MLD
Snooping
c
Standard Mode
c
Blocking Mode
a. These fields only appear when the "Enable DHCPv6 Server" field is activated (box checked).
b. These fields only appear when the "Enable RADVD" field is activated (box checked).
c. These fields only appear when the "Enable MLD Snooping" field is activated (box checked).
F@ST 2704R Reference Manual - 253526032-A
Enter the interface address.
Note: Entering a prefix length is mandatory.
Check the box to activate the DHCPv6 Server.
Using Stateless to achieve the IPv6 address for the LAN.
Using Stateful to achieve the IPv6 address for the LAN and fill
in the following fields:
Start interface ID: Enter the first interface identifier that is
assigned during stateful address autoconfiguration.
End interface ID: Enter the last interface identifier that is
assigned during stateful address autoconfiguration.
Leased Time (hour): Enter the time which lease for the client.
Uncheck the box to deactivate RADVD (Router Advertisement
Daemon) function.
Enable/Disable the ULA (Unique Local Address) prefix
Advertisement.
Enable/disable randomly generate the bellow parameters.
Enable/disable manually configure the bellow parameters.
Prefix: Enter the Prefix you wish to use. Prefix has an
associated valid and preferred lifetime, which constitutes an
b
agreement about the length of time over which the requesting
router is allowed to use the prefix
Preferred Life Time (hour): Enter the life time you wish to use.
Valid Life Time (hour): Enter the valid time you wish to use.
Check this box to activate the MLD (Multicast Listener
Discovery) protocol.
This lets you manage the declarations of belonging to one or
more groups with Multicast routers.
Check the box if you wish the MLD snooping runs in normal
mode.
Check the box if you wish the MLD snooping runs in blocking
mode.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Action
6- Advanced parameters
Default value
Empty
0:0:0:2
0:0:0:254
Empty
Checked
Page 6-49
