SAGEMCOM TalkTalk FAST 5364 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

TalkTalk Wi-Fi Hub (Sagemcom FAST 5364)

Table of contents

1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
2.4GHz Wi-Fi settings
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
Device Information
23.
24.
25.
26.
27.
28.
Page 1 of 38
Date: 25/06/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TalkTalk FAST 5364 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SAGEMCOM TalkTalk FAST 5364

Summary of Contents for SAGEMCOM TalkTalk FAST 5364

  • Page 1: Table Of Contents

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Table of contents Specifications Status light Login Dashboard Change router's admin password Internet settings Manage my devices Wi-Fi settings Ethernet & Wi-Fi settings Ethernet settings 2.4GHz Wi-Fi settings 5GHz Wi-Fi settings Guard Interval Band steering DHCP &...

  • Page 2: Specifications

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Specifications Parameter Available options Antenna Array 4x4 5GHz 3x3 2.4GHz Wi-Fi Class AC2200 Wi-Fi modes 2.4GHz 802.11 b/g/n 5GHz 802.11 a/n/ac Band steering is enabled, but cannot currently be disabled - notes 802.11ac specification 802.11ac Wave 2 using MU-MIMO Theoretical Link Rates 2.4GHz = 450Mb/s...

  • Page 3: Status Light

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Status light Unlike most routers, the TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) only has one status light on it. It is possible for the user to disable the light altogether via:- Dashboard > See internet settings > Manage advanced settings > TalkTalk WiFi Hub > Device Info >...

  • Page 4: Login

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Login Before trying to login, you need to find the default admin password. This is located behind a removable plastic panel along the top of the router where it has the inscription Pull up for...

  • Page 5: Dashboard

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Dashboard All three of the buttons from the dashboard:- • See internet settings • See W-Fi settings • Manage my devices On each of the resulting pages, there is a Manage advanced settings button which will take you to the TalkTalk Wi-Fi Hub page.
  • Page 6 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Dashboard to Wi-Fi Hub navigation The navigation on this part can be confusing, hopefully this will help:- Page 6 of 38 Date: 25/06/2018...
  • Page 7 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) TalkTalk Wi-Fi Hub On most pages that are accessed from the Wi-Fi hub there is a link top right, that will take you back to the Wi-Fi hub page. Page 7 of 38 Date: 25/06/2018...

  • Page 8: Change Router's Admin Password

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Change router's admin password Dashboard > See internet settings > Manage advanced settings > Access control > User tab Enter the old & new passwords in the following screen & click Apply:- Then log out, but first accept the prompt to save the configuration.

  • Page 9: Internet Settings

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Internet settings Dashboard > See Internet settings Page 9 of 38 Date: 25/06/2018...
  • Page 10 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Internet Configuration settings From any of the pages:- See internet settings See W-Fi settings Manage my devices Click on the Manage advanced settings button to get to the TalkTalk WiFi hub page:- Click on Internet connectivity:- This loads the Basic internet connectivity page, where the network DNS servers can be configured.
  • Page 11 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) ADSL:- Page 11 of 38 Date: 25/06/2018...

  • Page 12: Manage My Devices

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Manage my devices Dashboard > Manage my devices > Manage advanced settings The connected devices are shown in the red boxes below. Click on the device name to manage it:- In the screenshot below a friendly device name can be set & an icon selected:- Continued on next page.
  • Page 13 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) There seems to be a bug in the current firmware, as most of these icons are missing. The icons can be selected as shown:- However the missing ones do not appear along side the icon selected in Device Info & are not displayed in the Dashboard etc.

  • Page 14: Wi-Fi Settings

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Wi-Fi Settings Dashboard > See Wi-Fi Settings Page 14 of 38 Date: 25/06/2018...

  • Page 15: Ethernet & Wi-Fi Settings

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Ethernet & Wi-Fi settings Dashboard > See Wi-Fi Settings > Manage Advanced Settings On the dashboard there are three Manage advanced settings buttons (See internet settings, See W-Fi settings & Manage my devices) that all go to this TalkTalk Wi-Fi Hub:- These settings in more detail:- •...

  • Page 16: Ethernet Settings

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Ethernet Settings Dashboard > See Wi-Fi Settings > Manage Advanced Settings > Ethernet gear icon This looks far more like a stats display Page 16 of 38 Date: 25/06/2018...

  • Page 17: 2.4Ghz Wi-Fi Settings

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) 2.4GHz Wi-Fi Settings Here the SSID (network name), password, security modes (WPA2 etc) & channel settings can be changed within the 2.4Ghz band. Dashboard > See Wi-Fi Settings > Manage Advanced Settings > Wi-Fi 2.4Ghz gear icon > Basic Other tabs include:- •...
  • Page 18 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Dashboard > See Wi-Fi Settings > Manage Advanced Settings > Wi-Fi 2.4Ghz gear icon > WPS Connecting a device via WPS Follow the instructions that came with your device about connecting using WPS. When the device tells you to press the WPS button, on this router please:- •...
  • Page 19 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Advanced Dashboard > See Wi-Fi Settings > Manage Advanced Settings > Wi-Fi 2.4Ghz gear icon > Advanced Page 19 of 38 Date: 25/06/2018...
  • Page 20 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) MAC Address Filtering Dashboard > See Wi-Fi Settings > Manage Advanced Settings > Wi-Fi 2.4Ghz gear icon > MAC Filter Page 20 of 38 Date: 25/06/2018...
  • Page 21 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) 5GHz Wi-Fi Settings Here the SSID (network name), password, security modes (WPA2 etc) & channel settings can be changed within the 5Ghz band. Dashboard > See Wi-Fi Settings > Manage Advanced Settings > Wi-Fi 5Ghz gear icon > Basic Other tabs include:- •...
  • Page 22 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Dashboard > See Wi-Fi Settings > Manage Advanced Settings > Wi-Fi 5Ghz gear icon > WPS Connecting a device via WPS Follow the instructions that came with your device about connecting using WPS. When the device tells you to press the WPS button, on this router please:- •...
  • Page 23 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Advanced Dashboard > See Wi-Fi Settings > Manage Advanced Settings > Wi-Fi 5Ghz gear icon > Advanced 5GHz MAC Address Filtering Dashboard > See Wi-Fi Settings > Manage Advanced Settings > Wi-Fi 5Ghz gear icon > MAC...

  • Page 24: Guard Interval

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Guard Interval There is no option to configure the Guard Interval in the Wi-Fi settings. This is because, the router negotiates the GI with each device trying to connect to it. This is to give it the best Guard Interval (Long –...

  • Page 25: Dhcp & Lan Settings

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) DHCP & LAN Settings Dashboard > See Wi-Fi Settings > Manage Advanced Settings > TalkTalk WiFi hub > DHCP The router’s IP address & the DHCP server’s IPv4 address pool (address range) can be set here.

  • Page 26: Dhcp Reserved Ip Addresses

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) DHCP Reserved IP Addresses This function may come in later firmware release DNS servers handed out by DHCP for local clients Dashboard > See Wi-Fi Settings > Manage Advanced Settings > TalkTalk Wi-Fi Hub> DNS This is where the DNS servers hand out by the router's DHCP server to the attached local clients can be changed.

  • Page 27: Firewall

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Firewall Dashboard > See Wi-Fi Settings > Manage Advanced Settings > Access Control > Firewall Note that by default the router does not respond to pings. This is externally, it responds to pings like this OK from the internal network.

  • Page 28: Ddns

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) DDNS Dashboard > See Wi-Fi Settings > Manage Advanced Settings > TalkTalk Wi-Fi hub > DynDNS The tab name will hopefully be changed in the near future to DDNS to remove any confusion that it only supports the DynDNS DDNS provider.

  • Page 29: Port Forwarding

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Port Forwarding There are two ways to go into Port Forwarding Method 1 Go to:- Dashboard > My Devices Click on the device that you wish to forward to. Click on Port Forwarding Click Add Rule This will populate the Internal Host box of the Add Rule screen with that device's IP address.
  • Page 30 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Irrespective of the method used to arrive at the Add Rule Manually screen, the following fields need to be completed:- Parameter Notes Custom service name A unique name of your choice used to identify this port forwarding rule...
  • Page 31 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Port Forwarding status A summary list of any configured port forwarding rules can be seen at the bottom of the page:- The status of a rule can be On or Off in the Enable coloumn. Each rule can be edited or deleted via the icons in the Options column.

  • Page 32: Dmz

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Dashboard > See Wi-Fi Settings > Manage Advanced Settings > Access Control > DMZ Select a known device from the local host dropdown, or leave it set at other & type in its IP address...
  • Page 33 TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Device Info Dashboard > See internet settings > Manage advanced settings > TalkTalk WiFi Hub > Device Info > General This gives all sorts of information about the router. Device Note that the firmware version is called the Software version on this router. It can also be seen at the...

  • Page 34: Network Addresses

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Network addresses The Public IPv4 address (WAN IP address) can also be seen on the top right of some pages:- Wi-Fi basic statistics Page 34 of 38 Date: 25/06/2018...

  • Page 35: Dsl Statistics

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) DSL statistics (Fibre [VDSL] or ADSL) Page 35 of 38 Date: 25/06/2018...

  • Page 36: System Options

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) System Options Dashboard > See internet settings > Manage advanced settings > TalkTalk WiFi Hub > Maintenance From here there are the following tabs:- • Resets • Backup & Restore • Software Update •...

  • Page 37: Internet Time (Ntp)

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) Backup & Restore Dashboard > See internet settings > Manage advanced settings > TalkTalk Wi-Fi Hub > Maintenance > Backup & Restore Internet Time (NTP) Dashboard > See internet settings > Manage advanced settings > TalkTalk Wi-Fi Hub >...

  • Page 38: System Log

    TalkTalk Wi-Fi Hub (Sagemcom FAST 5364) System Log Dashboard > See internet settings > Manage advanced settings > TalkTalk Wi-Fi Hub > Maintenance > Logs Currently there are no quick ways to navigate the logs, only page by page & no way to send this to a syslog server.
