SAGEMCOM F@ST 2704R Reference Manual page 114

6- Advanced parameters
Add
• Click on the Add button to display the following screen:
Field
User Name
MAC Address
Days of the week
Start Blocking Time
(hh:mm)
End Blocking Time
(hh:mm)
Page 6-64
Enter a representative name for the LAN device.
Enter the MAC address of the required LAN device.
Note: To find out the MAC address of a Windows based PC,
open a command window and type "ipconfig /all".
Select the days of the week on which the restriction is effective
by checking the corresponding box.
Enter the required blocking start hour (for example 08:00).
Enter the required blocking end hour (for example 20:00).
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Action
F@ST 2704R Reference Manual - 253526032-A
