SAGEMCOM F@ST 2704R Reference Manual page 70

6- Advanced parameters
Field
Service Category
Select Scheduler
for Queues of
Equal Precedence
as the Default
Queue
Default Queue
Weight
Default Queue
Precedence
b
Peak Cell Rate
Sustainable Cell
c
Rate
Maximum Burst
c.
Size
a. This value is delivered to you by your Internet Service Provider (ISP).
b. This field only appears when the "UBR with PCR", "CBR", "Non Realtime VBR" or "Realtime VBR" type
of service is selected.
c. These fields only appear when the "Non Realtime VBR" or "Realtime VBR" type of service is selected.
Encapsulation modes
DSL Link type
EoA
(Ethernet over ATM)
PPPoA
(PPP over ATM)
IPoA
(IP over ATM)
Page 6-20
Select the type of service adapter to the traffic from the scroll
down list:
• UBR without PCR: Unspecified Bit Rate
• UBR with PCR: Unspecified Bit Rate
• CBR: Constant Bit Rate
• Non Realtime VBR: Variable Bit Rate
• Realtime VBR: Variable Bit Rate
These data packet scheduling techniques allow different
scheduling priorities to statistically multiplexed data flows.
Select in the drop-down list the required scheduler: Round
Robin (Weight=1) or Weighted Fair Queuing: (WFQ).
Enter the Weight Value of the default queue between 1 and 63.
Enter the precedence of the lowest queue between 1 and 8.
Enter a maximum number of cells transmitted per second,
between 1 and 2491.
Enter an average number of cells transmitted per second.
Note: This number must be lower than the Peak Cell
Rate (PCR).
Enter the maximum number of cells emitted in burst (value
between 1 and 1000 000).
Select the encapsulation of your choice from the scroll down list.
• LLC/SNAP-BRIDGING
• VC/MUX
Select the encapsulation of your choice from the scroll down list.
• VC/MUX
• LLC/ENCAPSULATION
Select the encapsulation of your choice from the scroll down list.
• LLC/SNAP-ROUTING
• VC/MUX
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Action
Action
F@ST 2704R Reference Manual - 253526032-A
Default
value
UBR
without
PCR
Round
Robin
(Weight=1)
1
8
-
-
-
Default
value
LLC/SNAP-
BRIDGING
VC/MUX
LLC/SNAP-
ROUTING
