6.4.1 Layer2 Interface

Object: This menu is used to configure DSL interfaces.
This section contains the following menus:
• ATM Interface (see subsection 6.4.1.1)
• ETH Interface (see subsection 6.4.1.3)
6.4.1.1 ATM Interface
Object: This menu is used to configure DSL ATM interfaces.
• In the Advanced Setup menu, select Layer2 Interface then ATM Interface.
The following screen opens:
Field
Interface
Vpi
Vci
DSL Latency
Category
Peak Cell Rate
(cells/s)
F@ST 2704R Reference Manual - 253526032-A
Name of the DSL ATM interface, allocated automatically.
Value of the VPI.
Value of the VCI.
DSL Latency.
Type of service adapter to the traffic.
Maximum allowable rate at which cells can be transported along the
connection in the ATM network.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
6- Advanced parameters
Meaning
Page 6-17
