Interface Grouping - SAGEMCOM F@ST 2704R Reference Manual

6.4.14 Interface Grouping

Object: This menu is used to host a service (Video, Data, SIP) on an interface (ETH or Wi-Fi) of your
router.
• In the Advanced Setup menu, select Interface Grouping.
The following screen opens:
Group Name
Remove
WAN Interface
LAN Interfaces
DHCP Vendor IDs
Note
By default, all the interfaces are dedicated to data and are associated with the first
VC (Virtual Channel) existing or created.
F@ST 2704R Reference Manual- 253526032-A
Field
Group name (see Note).
Check the box and click the [Remove] button to remove the
group.
WAN interface used.
Lists all your router's interfaces.
Note: This list depends on the network configuration.
DHCP Vendor IDs.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
6- Advanced parameters
Meaning
Page 6-87
